Honeycomb Fills – Ideal for Civil and Industrial Sewage Treatment

RuiD Cooling Tower Parts

As we all know, the cooling tower fills and drift eliminator are important components in the cooling towers. They are composed of several individual fill packs in PVC or PP materials. Several individual packs are hot pressed in constant temperature by the infrared ray to form the fill blocks. It has accurate specs, large specific surface area, safe, anti-corrosion, anti-aging and easy cleaning performance. Honeycomb fills refer to cooling tower fills and drift eliminator with hexagonal honeycomb profile for water treatment applications.

Honeycomb fills are precipitation packings developed based on shallow settlement. It has large wetted perimeter, small hydraulic radius. When operating, the honeycomb fills can supply good laminar conditions and ensure the high efficiency of particle precipitation without being disturbing by the turbulent flow. Additional, it can speed up the filtration of water and particle and shorten precipitation distance.

Item	Material	Specification	Raw Material Thickness (mm)	Sheet Quantity (pieces/m³)	Density (m³/mt)	Weight (kg/m³)
HFS-01	PVC	25	0.45	80	17.2	58
HFS-02	PVC	30	0.45	68	20.8	48
HFS-03	PVC	35	0.5	40	22.2	45
HFS-04	PVC	40	0.5	50	25	40
HFS-05	PVC	50	0.6	30	25	40
HFS-06	PVC	80	0.8	20	28.6	35
HFS-07	PP	25	0.5	80	22.2	45
HFS-08	PP	30	0.5	68	27.8	36
HFS-09	PP	35	0.5	40	23	32
HFS-10	PP	40	0.5	50	37	27
HFS-11	PP	50	0.6	30	21	28
HFS-12	PP	80	0.8	20	27	-

Features of honeycomb fills

Firm structure.
Large wetted perimeter.
Small hydraulic radius
Small volume.
Large specific surface area.
Anti-corrosion.
Anti-aging.
Temperature resistance.
Easy cleaning.
High treating efficiency.
Low maintenance.
Safe and non-toxic.
Wide range of applications.

Honeycomb fills types

Material:
- PP honeycomb fills.
- PVC honeycomb fills.
HF-01: PP material honeycomb fill pack.

HF-02: PVC material honeycomb fill pack.
Assemble structure:
- Straight type.
- Inclined type.
HF-03: Inclined type honeycomb fill.

HF-04: Straight type honeycomb fill.
Color:
- White.
- Blue.
- Black.
- Green.
HF-05: White color honeycomb fill.

HF-06: Blue color honeycomb fill.

HF-07: Black color honeycomb fill.
Function:
- Honeycomb cooling tower fills.
- Honeycomb drift eliminator.
HF-08: Honeycomb cooling tower fill.

HF-09: Honeycomb drift eliminator.
Other types of honeycomb fills

HF-10: Counter flow honeycomb fills.

HF-11: Biphasic weave honeycomb fills.

HF-12: Oblique weave honeycomb fills.

HF-13: Crossflow type honeycomb fills.

Applications of honeycomb fills

Inclined honeycomb fills. It is widely used for precipitation and degritting in new construction and reconstruction projects.
- Water inlet degritting.
- Domestic water precipitation.
- Sewage/waste water precipitation.
- Oil eliminator.
Straight inclined. Biochemical treatment for industrial organic waste water and civil waster water.
- High load biofilter.
- Tower biofilter.
- Submerged biological filter
- Microbial carrier of biological rotating disc

A piece of crossflow type honeycomb fills on the white background.

HF-14: Honeycomb cooling fills in the cooling tower.

Several blue color honeycomb cooling fills are inserted in the cesspit.

HF-15: Honeycomb cooling fills for sewage treatment.

Two cooling tower in the factory is production.
